Camera systems
The camera unit plays a central role in the visualisation system. The image transmitted by the endoscope is captured by one or more chips in the camera head and transmitted to the camera unit. There, it is processed and sent to the monitor for viewing. Various camera systems are available for different disciplines and requirements, offering resolutions ranging from Full HD to 4K.
All SPiTZ systems offer the advantage of being simple and intuitive to use. The entire system can be controlled with just a few actions. This can be done either via the device itself or via programmable control buttons on the camera head. All devices are also compatible with the various other devices in the SPiTZ imaging portfolio.
All camera systems can be equipped with an image and video storage function or connected to a PACS server via DICOM if required.
- Product-Highlights
- Product-Details
4K 3-Chip UHD Camera K4000
- 4K UHD resolution with 3-chip technology
- Image algorithm to enhance colour and texture
- 4K video recording
- 4K image storage
- Camera head with 4 programmable buttons
- Boost function
- Fog reduction
- Still image function
- 2.5x digital zoom
- 10 USER mode configurations
- Multilingual menu on the screen
- SDI 4K output
- Text generator (optional with keyboard)
Technical specifications
- Mains voltage: 100-240 VAC
- Power consumption: 60VA
- Image sensor: 3 MOS
- Resolution: 3840 x 2160 pixels (4K)
- Index ratio: 16:9
- N/N ratio: 54db
- Video outputs: 1x HDMI 4K, 1x HDMI FullHD, 1x SDI 4K, 1x SDI FullHD
- Control unit dimensions: 355 x 103 x 350m m (WxHxD)
- Weight control unit: 6.2kg
- Weight camera head: 145g
- USB recording function
The 3-chip camera system offers Full HD resolution (1920 x 1080 pixels) and 3-chip technology for natural colour reproduction. This versatile camera features various user modes and can be equipped with an optional integrated video and photo storage medium.
3 Chip HD Camera F4 & HD Camera F3 High End
- Full HD camera with 3-chip MOS technology
- Pure Natural Colours technology
- Full HD video recording
- Full HD image storage
- Camera head with 3 programmable buttons
- Boost function
- Freeze function
- 2.5x digital zoom
- 3 USER mode configurations
- Multilingual on-screen menu
- Various digital video outputs
- Text generator (optional with keyboard)
Technical data
- Mains voltage: 100-240 VAC
- Power consumption: 60VA
- Image sensor: 3 MOS
- Resolution: 3840 x 2160 pixels (4K)
- Index ratio: 16:9
- N/N ratio: 54db
- Video outputs: 1x HDMI 4K, 1x HDMI FullHD, 1x SDI 4K, 1x SDI FullHD
- Control unit dimensions: 355 x 103 x 350m m (WxHxD)
- Weight control unit: 6.2kg
- Weight camera head: 145g
Technical highlight of the 3 chip HD camera F4:
- USB recording function
The FullHD system is an excellent, high-resolution solution for all areas, especially private practices. The F2/F1 line is very simple to operate and highly reliable, making it a dependable system for all applications.
HD camera F2 PRO & HD camera F1
- Full HD camera with 1-chip MOS technology
- Natural colour technology
- Full HD video recording
- Full HD image storage
- Camera head with 3 programmable buttons
- Boost function
- Freeze function
- 2.5x digital zoom
- 3 different programmable user modes
- Multilingual on-screen menu
- HDMI video outputs
- Text generator (optional with keyboard)
- With USB recording function
Technical data
- Mains voltage: 100-240 VAC
- Power consumption: 60VA
- Image sensor: 3 MOS
- Resolution: 3840 x 2160 pixels (4K)
- Index ratio: 16:9
- N/N ratio: 54db
- Video outputs: 1x HDMI 4K, 1x HDMI FullHD, 1x SDI 4K, 1x SDI FullHD
- Control unit dimensions: 355 x 103 x 350m m (WxHxD)
- Weight control unit: 6.2kg
- Weight camera head: 145g
- USB recording function
Technical highlight of the F2 PRO HD camera:
- USB recording function
The integrated Full HD camera and LED light source is a 2-in-1 combined system. It is specially designed for use in outpatient settings.
The C2 camera system supports rigid and fibre
endoscopes. With its small base, it offers
an economical and flexible solution for endoscopic diagnostic and surgical
procedures in gynaecology, urology and ENT.
C2 camera system
- Compact and integrated 2-in-1 design
- Versatile use for rigid and fibre endoscopes
- LED lamp – with an exceptionally long service life
- Silent ventilation system
- Easy storage and documentation of videos
and images - Optional TV adapters with fixed focal length or zoom available
